CNC Turning- and Milling Center
BOLEY BE 42
- Stock number:
- 1070-100724
- Year / Condition:
- 2007
- Control unit:
- CNC (Mitsubihi Meldas)
- Country of origin:
- Germany
- Freight basis:
- EXW (Incoterms 2010) free loaded on truck
- Item location:
- South Germany
- Delivery time:
- Immediately
Picture / documents / videos
Technical specs
Details
- standard turning dia.:
- 42 / 140
- turning length:
- 170 mm
- control:
- Mitsubishi
- max. turning diameter:
- 140 mm
- bar material dia.:
- 42 mm
- turning speed range - spindle:
- 80-8000 1/min
- spindle bearing diameter:
- 120 mm
- C-Axis:
- 0,001 °
- turning speed range - spindle:
- 60-6000 1/min
- spindle nose:
- JIS A2-6
- bar material dia. max:
- 42 mm
- collet chuck:
- 173E
- C-Axis:
- 0,001 °
- Number of Turrets:
- 2 .
- Number of tool stations:
- 12 x 2=24 pos
- power capacity - driven tools:
- 7,5 / 5,5 kW
- total power requirement:
- 92,7 kVA
- weight of the machine ca.:
- 3,3 t
- dimensions of the machine ca.:
- 2,4 x 1,6 x 2,2 m
Accerories
- Chip conveyor
- Coolantsystem
Description
The Boley BE 42 2 has 2 spindles und 2 turrets with 12 toolstations VDI 20 each.
It can work simultaneus with 7 Achsen.
The machine has ca. 22.000 run hrs.
The coolant system has a cooling unit
15 collets 173E come with the machine.
A bar feeder interface is installed.
