Details

turning diameter:

800 mm

turning length:

3000/4000/5000 mm

control:

SPS

bed width:

600 mm

max. swing over slide:

480 mm

spindle taper:

A-11

spindle bore:

104 mm

spindle speed:

14-1000 1/min

with constant cutting speed:

und stufenloser Drehzahl

transmission ratio:

4-stufig

tailstock quill diameter:

75 mm

tailstock quill stroke:

150 mm

chuck size:

350 mm

rapid traverse x/z:

4/8 m/min

tailstock quill diameter:

100 mm

tailstock quill stroke:

250 mm

taper of tailstock quill:

5 MK

frequency conversion motor power:

15 kW

weight of the machine ca.:

6.5 / 7.5 / 8.5 t

dimensions of the machine ca.:

5085x1780x1780 / 6085x1780x1780 / 7085x1780x1780 mm

Accerories

electric handwheel



cooling system



tools



coolant system



swivellable control



tech. documentation



LED work light



stepless speed



tool holder:

4

coolant splash guards on the backside



LCD Touchscreen with PLC control



Servo motors



dead center



electrical chuck guard



turret cover



CE and declaration of conformity



chip bin, removable



3 jaw chuck Ø:

380 mm

Description

100 % before loading

warranty:
12 month

main features:
-high speed
-high spindle torque
-big spindle bore
-automatic forced lubrication
-hardened and ground guideways
-brand-new design eterior
-CE certificate of TÜV Rheinland, Germany & ISO 9001 CQC, China

steady rests
quick change tool post (German style)
more options upon request
