Details

bore capacity in steel (diameter):

18 mm

throat:

250 mm

bore stroke:

100 mm

drill capacity in cast iron:

Ø 23 mm

metrical thread cutting:

ST60: M10 / GG20: M 14 M

spindle taper MT:

MK 2

spindle speed::

400 - 630 - 1000 - 1600 - 2500 U/min

feed:

manuell mm/U

Distance spindle/table max.:

75 / 605 mm

table clamping surface::

250 x 250 mm

column diameter:

Ø 90 mm

total power requirement:

0,55 kW

weight of the machine ca.:

ca. 170 kg

dimension machine approx.LxWxH:

0,4 x 0,8 x 1,8 m
