Details

x-travel:

3.000 mm

y-travel:

800 mm

z-travel:

1100 mm

turning speed range - spindle:

12.000 U/min

power capacity:

30 kW

Spindle Torque:

190 Nm

tool taper:

HSK 63 A

bore capacity in steel:

60 mm

Max. Milling-capacity:

500 cm³/min

threading:

M 30

rapid traverse in x-y-z axis:

30

feed speeds:

30.000 mm/min

table surface area:

3.500 x 835 mm

T-slots:

7x

T-slot - width:

18-H7 mm

with NC rotary table:

Sempuco SKH 4/630

faceplate diameter:

630 mm

numbers of positions in the tool changer:

48

weight of the machine ca.:

15 t

Description

NC-Swivel-Head:
Sauter
Pivotabel +/- 90 Grad
Division +/- 3 Bogensekunden

Full workspace encapsulation
Loading doors suitable for crane loading
Automatic opening
Movable partition wall

Coolant system:
Internal coolant supply 70 bar
Paper belt filter
Spray gun
Chip vonveyor discharge height 1200mm

Clamping hydraulics
Interface 4 axis
3D wireless probe
Direct measuring systems x-y-z
Cooling aggregate for enclosure
NC-rotary table RW/NC 160/250 Hofmann
Face plate diameter 250mm
Tip height 160mm
Hydraulic taistock with quill MK4
Documentation
Declaration of conformity

Replacement screen installed
