Description

RUWI underfloor milling base 1

The 1-he is like RUWI placed next to the CNC machine. waiting times
can be used for operations such as chamfers, rounds or deburring
be.

Accessories (can be retrofitted)

A try square, arc ruler, mounting brackets, mounting rail,
Table extension, application examples on the RUWI YouTube video channel

Technical Specifications:
- Variable speed control 8000-25000 U / min.
- Electronic control system prevents speed variations under load
- Overload protection and PTC thermal monitoring
- Robust and heavy-duty motor with 1050 watts for
the industiellen continuous use
- Made in Germany
- Soft start and starting current limitation
- Voltage 230 V
- Milling spindle with 22 mm diameter counter-rotating and return screw threads
for dirt defense, precise double bearing for precise milling patterns
- Chip pickup in steel
- Collets 8 mm (standard) optiona 6 mm or 6.35 mm
- Exhaust connection 120 mm


factory
