Details

turning diameter over bed

530 mm

turning diameter over slide rest

325 mm

turning length

3000 mm

turning dia. in gap

780 mm

length of gap

215 mm

spindle passage

68 mm

turning speed range

30 - 1500 U/min

no. of turning speeds

12

feeds - longitudinal

0,05 - 1,5 mm/U

feeds - cross

0,025 - 0,75 mm/U

centre height

260 mm

taper in tailstock MT

5

tailstock quill diameter

72 mm

tailstock quill stroke

180 mm

centre distance

3150 mm

total power requirement

5,7 kW

weight of the machine ca.

2,3 t

dimensions of the machine ca.

4,5 x 1,1 x 1,7 m

Control unit

conventional
