Details

faceplate diameter:

5000 mm

swing diameter:

5200 mm

turning height:

3000 mm

max. turning diameter:

5200 mm

Travel of Ram (vertical):

1500 mm

Travel of ram (horiz.):

+/- 2500  mm

ram stroke speed:

15000 mm/min

cutting capacity:

150000 Nm in X-/Z-Achse

ram head dimension:

400 x 400  mm

Accerories

CNC controller:

Siemens/Fanuc/Fagor

CE-design





Rams:

2 Stk.

chip conveyor with chip bucket



c-axis



Scales:

v. Heidenhain



coolant system



automatic tool changer

 fach

Oil-coolant separator



Machine semi-cover



4-jaw faceplate Ø





signal lamp



heat exchanger for electr. cabinet



hydraulic unit



Auto gear change system



levellig elements



gear box



autom. balancing system for Z-axis



European electric



servo motors:

Siemens/Fanuc/Fagor

machine tools



operator platform



tool holder



Description

Chip Conveyor
Coolant Tank
Oil/Water Separator
Machine Cover (High guarding)
Heat exchanger For Electrical Cabinet
Auto Lubrication for Guide way
4 Jaw Manual Chuck 1600mm
Hydraulic Unit
BT50 Tool Connection in RAM
Metal frame and case in machine shipment packing(Wooden packing with metal base)
3 colors Warning Light
Chamber light
Anti- Dropping in Z axis -- Auto Motor Brake System
Options Installed
Air Conditioner For cabinet
Coolant Through Spindle
Filter for Coolant Water
CE Mark
Transformer

hydr. chuck
c-axis
CNC controls from
y-axis
paper and magnetic filter
CTS
autom. doors
automatic pallet changer APC
air condition for the cabinet
ATC
higher column
tool measuring system
workpiece measurement system
