Details

throat:

1000 mm

pressure capacity max.:

80 t

working area:

2000 x 1000 mm

2 supporting tables front:

1 x 600 x 600 mit 12 Kugeln

1 x 600 x 400 mit 12 Kugeln

edge with measuring scale-4 metal support brackets:

2000 mm

1 support arm sideways, with scratch gauge:

1400 mm

1 support arms:

800 mm

max. punching diameter, round St37:

60 mm

ring and straight cuts:

max. 5 mm

R40:

2 mm

R70:

1,5 mm

C:

6 mm

round cutting until:

1000 mm Ø

total power requirement:

380 50 2,5 V Hz kW

weight of the machine ca.:

2200 kg

dimensions of the machine ca.:

2550 x 2550 x 1800 m

Accerories

coordinates direction



copying template



gill tool top/down



22 punches



31 matrixes:

3,5/6,5/8/8,5/10/12/14 Ø

10 Vierkant
