Details

turning diameter over bed

300 mm

turning diameter over slide rest

170 mm

turning length

750 mm

max. turning diameter without bridge

430 mm

spindle bore

38 mm

spindle cone

MK 5

spindle taper

DIN 55027

tool holder

16 x 16 mm

tailstock cone

MK 3

no. of turning speeds

9

speeds:

60-2000 U/min

feeds - longitudinal

0,03-0,43 mm/U

feeds - cross

0,015-0,21 mm/U

metric threading

0,25-9 mm

thread - inch

4 3/4 - 72 TPI

diametral

8-144 D. P.

max. module

0,25 - 3,5 mm

total power requirement

1,1 kW

dimensions of the machine ca.

1530 x 650 x 1175  mm

weight of the machine ca.

470 kg

Control unit

conventional
