Details

turning diameter:

490 mm

turning length:

1.000 mm

total power requirement:

15/20 kW

weight of the machine ca.:

3,6 t

dimensions of the machine ca.:

2,8 x1,85 x 1,9 m

Description

In like new condition
Heidenhain cycle control
Torsion-resistant bed, made of high-quality cast iron with hardened, precision-ground guideways and a glass scale on the X-axis
Safety clutch on the Z and X axes
Sealing air with carbon filter in direct position measuring system
High accuracy and rigidity of the lathe spindle thanks to precision spindle bearings, spindle bore Ø 93 mm standard, optional Ø up to 130 mm
Solid tailstock, quill Ø 90 mm with internal taper MK5
Large overhang above the facing slide for easy accessibility during shaft machining.
