Details

spindle diameter:

82 mm

x-travel:

1400 mm

z-travel:

850 mm

y-travel:

900 mm

w-axis:

370 mm

table-size:

1000 x 1000 mm

tablesize with extension:

1345 x 1000 mm

table load:

2000 kg

distance spindle center to table::

0 - 1100 mm

distance between columns:

1855 mm

distance spindle center to column:

270 - 1270 mm

bore capacity in St 60 - full boring:

45 mm

bore capacity in cast iron:

70 mm

spindle taper:

MK5

spindle motor:

6 kW

spindle turning speed range:

30 - 1500 U/min

control:

Heidenhain TNC 360

weight of the machine ca.:

8000 kg

dimensions of the machine ca.:

2600 x 3600 x 3700 mm
