Center Lathe
ZMM SLIVEN CU 1000 RD
- Stock number:
- 1087-0303092
- Year / Condition:
- 2011
- Control unit:
- conventional
- Country of origin:
- Bulgaria
- Freight basis:
- EXW, free on truck unpacked
- Item location:
- Leipzig 5
- Delivery time:
- by arrangement
Picture / documents / videos
Technical specs
Details
- turning diameter over bed:
- 1090 mm
- turning diameter over support:
- 690 mm
- turning length:
- 1100 mm
- centre distance:
- 6000 mm
- turning dia. in gap:
- 1250 mm
- centre height:
- 500 mm
- spindle passage:
- 152 mm
- range of revolution per miute:
- 6,3 - 1250 U/min
- face slide travel:
- 525 mm
- tailstock quill taper MT:
- MK 6
- tailstock quill adjustment::
- 260 mm
- cross feed:
- 0,016 - 19,45 mm/U
- longitudinal feeds::
- 0,032 - 38,9 mm/U
- number of feeds:
- 160
- spindle bore:
- 155 mm
- total power requirement:
- 30 kW
- weight of the machine ca.:
- 10,65 t
- dimension machine approx.LxWxH:
- 8,3 x 2,0 x 1,90 m
Description
The machine is equipped with:
Digital Readout (DRO)
4-position tool post
Tailstock
Rapid traverse
Lead screw and feed rod
Heavy-duty machine bed
Conventional design
