Details

turning diameter over bed

800 mm

turning diameter over support

500 mm

turning length

3000 mm

center height over bed

550 mm

centre distance

2100 mm

spindle bore of work spindle

Ø 85 mm

range of revolution per miute

8 - 1250 / 24 step U/min

feeds:

längs: 0,054 - 10 / 44 step mm

tailstock quill taper MT

MK 5

tailstock quill adjustment:

350 mm

total power requirement

 kW

weight of the machine ca.

4,9 t

dimension machine approx.LxWxH

3,2 x 1,5 x 1,5 m

Control unit

conventional

Manual

1
