Details

turning diameter over bed:

1200 mm

turning diameter over support:

800 mm

turning length:

3200 mm

length of gap:

600 mm

center height measured in bed:

600 mm

turning dia. in gap:

600 mm

spindle turning speed - continuous:

4,6-545 / 22 steps U/min

spindle passage:

90 mm

feed:

1,4-510 m/min

taper:

MK6

total power requirement:

15 kW

weight of the machine ca.:

10,0 t

dimensions L x W x H:

6,20x2,00x1,80 m

dimensions electric cabinet LxWxH:

0,55x0,33x1,0 m

Description

equipped with:
face chuck diameter 1000m (4 jaw chuck)
fourfold chisel taper
steady rest closed, inside diameter 250mm
revolving tail center
conical turning device
