Details

bore capacity in steel (diameter):

23 mm

workpiece height max.:

./x. 205 / 655 mm

drill capacity in cast iron:

Ø 26 mm

spindle taper:

MK 3

bore spindle stroke:

135 (manual/automatic) mm

range drill spindle revolution per minute:

70 - 1550 / 8step U/min

feed range:

0,075; 0,15; 0,30 mm/U

Table dimensions:

1200 x 500 mm

table surface area:

1070 x 400 mm

total power requirement:

3,55 kW

weight of the machine ca.:

1,4 t

dimension machine approx.LxWxH:

1,7 x 1,2 x 2,2 m
