Details

grinding length

1000 mm

grinding width

500 mm

workpiece height

625 mm

table-size

1200 x 450 mm

max. table load

1380 kg

dist. center of grinding spindle - table

180 - 825 mm

table travel longitudinal

1150 mm

table travel cross

500 mm

table feed

2 - 28 m/min

power capacity - grinding motor

9,0 kW

grinding wheel size

400 x 100 x 127 mm

magnetic clamping plate

1000 x 500 mm

dressing device

Kopfabrichter

voltage

400 V

total power requirement

14,4 kW

weight of the machine ca.

4,3 t

dimensions of the machine ca.

3,85 x 2,70 x 2,45 m

switchgear cabinet

1,10 x 0,40 x 1,80  m

hydraulic power unit

1,00 x 0,70 x 0,80 m

1,40 x 1,00 x 0,80 m

Control unit

conventional
