Details

x-travel

1000 mm

y-travel

510 mm

z-travel

510 mm

control

Fanuc MSX 501 Mapps

Spindle RPM

14000 1/min

spindle drive

22/18,5 kW

rapid travel x/y/z

42 mm/min

Pallet changer 2x

1200 x 480

workpiece weight

1200 kg

tool magazin:

30 HSK 63

tool changing time

0,9 sec

distance spindle nose and table

150-660 mm

distance spindle center to column

660 mm

total power requirement

51 kVA

weight of the machine ca.

6,96 t

dimensions of the machine ca.

2,78 x 4,0 x 2,65 m

Control unit

CNC

Maker of control unit

MSX 501 MAPPS 3

Accerories

1 chip conveyor



Coolant through spindle 50 bar with filter

Knoll SF 500
