Details

x-travel

1450 mm

y-travel

700 mm

z-travel

550 mm

control

Heidenhain iTNC 640

table surface area

1700 x 750 mm

workpiece weight

2000 kg

turning speed range

18.000 U/min

power capacity

15 kW

max. torque on the spindle

130

Tool magazine

60 SK 40

workpiece diameter at full load

80 mm

wotkpiece diameter with 2 vacant positions

100 mm

tool length - max.

300 mm

feed range

0 - 42.000 mm/min

rapid travel range

42 m/min

total power requirement

30 kW

dimensions of the machine ca.

3,0 x 2,8 x 2,5 m

weight of the machine ca.

8,5 t

chip conveyor



Control unit

CNC

Maker of control unit

iTNC 640

Accerories

BLUM laser for tool measuring



cooling

20 bar

Electronic handwheel



DXF import function
