Details

turning diameter

120 mm

turning length

100 mm

control

Fanuc

Spindle 1 power

7,5 kW

Spindle 1 RPM

4500 1/min

Spindle 2 power

7,5 kW

Spindle 2 RPM

4500 1/min

Distance between spindle noses

600 mm

Turret No.1 stations / rotary tools

15/15

Power rotary tools turret 1

2,7 kW

RPM of rotary tools turret 1

4000 1/min

Turret No.2 stations / rotary tools

15/15

Power rotary tools turret 2

2,7 kW

RPM of rotary tools turret 2

4000 1/min

Travel x/z turret 1

250 / 300 mm

Travel x/z turret 2

250 / 920 mm

Bar capacity spindle 1

51 mm

Bar capacity spindle 2

51 mm

power chuck

165 mm

Spindle bore sp. 1

62 mm

Spindle bore sp. 2

62 mm

dimensions of the machine ca.

3700 x 2300 x 3000 mm

weight of the machine ca.

5600 kg

Control unit

CNC

Maker of control unit

FANUC
