Details

turning diameter

200 mm

turning length

455 mm

control

Soemens 840 D Shopmill MAPPS

swing diameter over slide rest

260 mm

bar diameter

51 mm

drive capacity - spindle motor

16,5 kW

Spindle RPM

5000 1/min

Spindle Torque

166 Nm

spindle nose

140 h5

C-Axis

0,001°

spindle bearing diameter

130 mm

turret stations / rotary tool stations

12/12 VDI 30

Power rotary tools

9,42/7,5 / 4,2 kW

RPM of rotary tools

4500 1/min

Programmable Tailstock



tailstock quill taper MT

4

Tailstock Travel

396 mm

rapid traverse X-axis

30 m/min

rapid traverse Z-axis

30 m/min

travel -x axis

182,5 mm

travel -z axis

455 mm

total power requirement

34 kW

weight of the machine ca.

3,8 t

dimensions of the machine ca.

4,3 x 2,3 x 2,2 m

Control unit

CNC

Maker of control unit

Siemens 840 D Shopmill

Accerories

Chip conveyor



3-Jaw Chuck

210 mm

High pressure coolant 12 bar
