Details

pressure:

1000 t

distance between columns:

3030 mm

stroke:

350 mm

Distance table/ram, max. stroke up, adjustment up:

1400 mm

table surface area:

3000 x 2000 mm

table height over floor:

430 mm

side window:

1450 x 1400 mm

ram surface:

3000 x 2000 mm

speed down:

300 mm/s

speed up:

340 mm/s

working speed:

18 - 44 mm/s

return capacity:

120 t

oil volume:

4400 l

width with platform:

4950 mm

power capacity:

2 x 90,0 + 10,0 kW

weight:

87,0 t

Dimensions (WxDxH):

4,35 x 3,65 x 7,55 m

height over floor:

6,05 m

height beneath floor:

1,5 m

Additional information

German Safety: permitted for manual loading
conrollable dependant on pressure/time and way
ram interlocking
two-hand operation
