Details

x-travel:

8000 mm

y-travel:

3000 mm

cutting range for steel to:

stainless steel 1-25 (30) mm

cutting range for steel to:

soft steel 2-16 mm

cutting range for steel to:

alloyed steel 1-35 mm

control:

DIGISAF 3.5 BURNY

burner type:

CPM 250-Flache Elektrode

table height:

800 mm

interface:

RS 232

total power requirement:

ca. 80 kVA

weight of the machine ca.:

8 + 5 (Wanne, Basin) t

Description

Plasma Cutting Plant

possible welding processes:
- Plasma Cutting, Plasma Gouging, WIG(TIG) on all metals and alloys, MIG on light metals and alloys and heavy metals, Arc-Welding
- power source: Nertajet HP 120 (220V,24V,380V,415V,440V,500V) multiple frequencies 50/60Hz
- plasma torch: CPM 250 (flat electrode), Cutting method under water, plasma cutting, cutting speed
- approx. 8m /min, marking via drill(driven by air pressure)
- equipment: rail guides, cabinet, cutting portal, burning supports, 1x torch

machine measurements:
- cutting device: L:4,40xW:2,30xH:1,80m
- cutting table: L:8,44xW:3,31xH:0,85m
- Plasma Generator: L:0,83xW:0,65xH:1,33m / 2 pcs available
- Track 1: L:10,650xW:0,25xH:0,92m left side
- Track 2: L:10,650xW:0,25xH:0,57m right side
- Workpiece supports:L:3,120xW:1,36xH:0,14m 5 pcs. f. cutting table
- Water tank: D=1100mm H=2000mm / 1x
- storage tank: 1,20mx1,03x1,6m

further details:
- number of burner: 1x
- cutting process under water plasma cutting
- cutting speed approx. 8m/min.

Documentation available!
