Details
- x-travel
- 6450 mm
- y-travel
- 2800 mm
- z-travel
- 1100 mm
- distance between columns
- 2800 mm
- table width
- 2200 mm
- table length
- 6000 mm
- distance spindle nose and table
- 615-1715 mm
- cross section of ram
- (4 Führungen): 450*400 mm
- spindle cone
- 50 BBT (opt.SK)
- turning speeds
- 8000 1/min
- spindle drive
- 1PH8137: 22/26kW + Getriebe (1:4)
- feed speeds
- 15/15/12 m/min
- machine length
- 12,5 m
- machine width
- 6,6 m
- height of the machine
- 5,1 m
- Weight approx.
- 34 t
- Control unit
- CNC
- Maker of control unit
- SIEMENS 840D+15"LCD
Accerories
- automatic tool changer
- optional
- CNC controller
- SIEMENS 840D+15"LCD
-
- 3 chip conveyor
-
- chip conveyor
- Schnecke 2 Stück
- automatic stepless gear box
-
- angular milling head
- 90°-Fräskopf (automatische Kopfbefestigung (AAC), automatischer 5°-Index (AAI), Werkzeugfixierung durch Fußschalter, 3500 U/min, 1000Nm)
- heat exchanger
-
- Ethernet interface
-
-
- signal lamp
-
- CE and declaration of conformity
-
- gear box
-
- automatic cooling and lubrication system
-
- Telescope cover for guideways
- für die X-/U-Achse
-
- Scales
- in X/U/Y/Z-Achse
- cloth cover
- für die Y-Achse (JAVARA)
- foundation bolts and pads
-
- MPG hand wheel
-
- Moving operator room
- verfahrbar
- foot pedal
- für Werkzeugwechsel
- inner coolant
- vorbereitet
- spindle coolant system
-
- spindle air blow
-
- ball screw in axes
- Y- und Z-Achse
- rack movement
- X- und U-Achse
